Din rail mountable single-phase power supply features a rugged metal casing that protects from short circuits, overload, overvoltage, and over-temperature. Offers a universal input of 85 to 264 V AC and a single output of 24 V DC 3.2 A.
Din rail mountable single-phase power supply features a rugged metal casing that protects from short circuits, overload, overvoltage, and over-temperature. Offers a universal input of 85 to 264 V AC and a single output of 24 V DC 3.2 A.
Discontinued!
This product has been discontinued and is no longer available.
This is the direct replacement:
Features
| Output DC Voltage |
| 24 V |
| Rated Current |
| 3.2 A |
| Current Range |
| 0 to 3.2 A |
| Input Voltage Range |
| 85 to 264 V AC / 120 to 370 V DC |
| Frequency Range |
| 47 to 63 Hz |
| Efficiency |
| 80% |
| Maximum AC Current |
| 1.6 A / 115 V AC 0.96 A / 230 V AC |
| Safety Standard |
| UL508 / EN60950-1 compliant |
| Output DC Voltage |
| 24 V |
| Rated Current |
| 3.2 A |
| Current Range |
| 0 to 3.2 A |
| Input Voltage Range |
| 85 to 264 V AC / 120 to 370 V DC |
| Frequency Range |
| 47 to 63 Hz |
| Efficiency |
| 80% |
| Maximum AC Current |
| 1.6 A / 115 V AC 0.96 A / 230 V AC |
| Safety Standard |
| UL508 / EN60950-1 compliant |
