DIN rail mountable single-phase power supply enclosed with fully isolated plastic case and protection from short circuits, overload, and overvoltage. Offers a universal input of 85 to 264 V AC and a single output of 24 V DC 4 A.
DIN rail mountable single-phase power supply enclosed with fully isolated plastic case and protection from short circuits, overload, and overvoltage. Offers a universal input of 85 to 264 V AC and a single output of 24 V DC 4 A.
Ideal for low-wattage DIN rail applications, the PS-S SlimLine series power supply features a fully isolated plastic enclosure for full protection from hazardous shock in space-saving slim constructions. Offers a lower power consumption that significantly expands the application of the PS-S SlimLine series for the industrial field to datacom or IT applications that require energy saving and green power to meet environmental regulations and laws soon!
Features
| Input Voltage Range |
| 85 to 264 V AC; 120 to 370 V DC |
| AC Inrush Current (Maximum) |
| Cold start: 20 A at 115 V AC,; 40 A at 230 V DC |
| DC Adjustment Range |
| ±10% rated output voltage |
| Overload Protection |
| 105% to 160% constant current limiting (auto- recovery) |
| Over-Voltage Protection |
| 115% to 135% rated output voltage |
| Setup, Rise, Time (Maximum) |
| 500 ms, 30 ms/230 V AC 1000 ms, 30 ms/115 V AC, at full load |
| Withstand Voltage |
| I/P-O/P: 3 KV AC, I/P-FG:1.5 KV AC, O/P-FG:0.5KV AC |
| Working Temperature |
| -4 to 158°F (-20 to 70°C), refer to output derating curve |
| Safety Standards |
| UL508, EN60950-1 |
| EMC Standards |
| EN55022 class B |
