Ametek Crystal XP3i Series Digital Absolute Pressure Gauge, 0 to 100 psiA, 4.5" dial, ¼" NPT bottom, diecast aluminum housing

Model: XP3I-A100PSI

Ametek Crystal XP3i Series Digital Absolute Pressure Gauge, 0 to 100 psiA, 4.5" dial, ¼" NPT bottom, diecast aluminum housing-

Image is for reference only, refer to product info for complete details.


Downloads:

Ametek Crystal XP3i Series Digital Absolute Pressure Gauge, 0 to 100 psiA, 4.5" dial, ¼" NPT bottom, diecast aluminum housing

Model: XP3I-A100PSI

Ultra-rugged and intrinsically safe, this easy-to-use digital pressure gauge covers a wide pressure range and comes with Bluetooth connectivity for convenience and efficiency in the field. In addition, this pressure gauge measures absolute pressure from 0 to 100 psiA with a ±0.05% reading accuracy.

Ultra-rugged and intrinsically safe, this easy-to-use digital pressure gauge covers a wide pressure range and comes with Bluetooth connectivity for convenience and efficiency in the field. In addition, this pressure gauge measures absolute pressure from 0 to 100 psiA with a ±0.05% reading accuracy.

Sale Price $2017.28 USD
Regular Price $2048.00 USD
Availability 2 Days
Quantity

Crystal Pressure XP3I-A100PSI Offers

Accuracy is 0.05% 'of reading', 0.02% 'of full scale', or 0.05% 'of full scale' - so any XP3i can typically replace several gauges you may have been using. The XP3i is fully temperature compensated – so there is no change in accuracy throughout the entire operating temperature range! The XP3i's case is made from rugged aluminum alloy, fully sealed against dust and water intrusion. Even the USB port is sealed. Circuitry is mounted in shock-absorbing elastomer supports and the batteries are accessible by removing four screws. However, you won’t need to change the batteries often, since 3 AA batteries operate this pressure gauge for up to 1500 hours of continuous use.

Now with USB-C and Bluetooth connections, a free mobile app, and a cloud software service, you can share stored files with any colleague with internet access. In addition, if a recording of a pressure test is required, add the DataLoggerXP upgrade (sold separately) to open a wide range of features and functions.

Features

  • Series ranges up to 10,000 psi, 700 bar, or 70,000 kPa depending on the model purchased
  • Marine grade enclosure resists corrosion (MIL-STD 810)
  • Accuracy not affected from -4 to 122°F (-20 to 50°C)
  • Replaces five or more test gauges
  • Fast pressure safety valve (PSV) mode
  • Easy to use: No menu, no manual, no problem
  • Includes calibration reminders and alerts
  • Bluetooth™ low energy interface to the CrystalConnect mobile app
  • Data logger (sold separately) with extremely large capacity
  • Continuous capture of peak and valley pressure readings
  • Programming interface
  • User-defined units
  • Intrinsically safe: Meets the latest standards as a digital test gauge
  • All welded 316 stainless steel sensor for ranges above 15 psi/1bar

With a Bluetooth connection, you can:

  • Connect in a hazardous environment while retaining intrinsically safe ratings
  • Mount the XP3i in hard-to-reach locations and connect from a safe area
  • Avoid inclement weather by connecting to the XP3i from a climate-controlled office or vehicle
  • Forgot your communication cable? Are drivers not installed? Is the cable damaged? All of these problems go away with a Bluetooth connection!

With the DataLoggerXP upgrade (sold separately)

  • Record over 200 million data points
  • Over an entire year of continuous recording time
  • Start and stop logging runs from your phone or the gauge
  • Download data using a USB connection and a computer or through Bluetooth to the mobile app

With the new CrystalControlWeb cloud software (free for download)

  • Upload stored data from your computer
  • Upload stored data from a file - wirelessly downloaded using your app
  • Share stored data with anybody in your organization
  • Grant user access to your organization through a license key
  • Graph your stored data
  • Customized graph details like line color, axis minimum and maximums, and run and test names
  • Configure the settings on your XP3i
  • Download data to spreadsheets or secure, tamper-proof pdf files

The best is now better!

The new XP3i takes everything you love from the XP2i, like:

  • Easy to use: Just pick up an XP3i and you'll be an expert in minutes. It's as easy as that.
  • Field proven - durable and rugged: Weather tested and drop protected, this pressure gauge is designed to withstand the toughest conditions where you rely on trusted pressure readings.
  • Reliable accuracy whenever: This digital gauge is used in some of the most extreme locations in the world and was designed with temperature compensation to support you wherever you work.

…and adds game-changing features

  • Bluetooth communication: No need to connect to the XP3i by a cable - quickly connect wirelessly using our new CrystalConnect mobile app. Ideal to avoid hazardous locations, inclement weather, and hard-to-reach locations.
  • Twice as accurate as the XP2i: Now with an accuracy of 0.05% of reading, use the XP3i in more places, and replace even more standard gauges. Additionally, this increased accuracy is over a larger temperature-compensated range of -4 to 122°F (-20 to 50°C).
  • Cloud solution: The new cloud software CrystalControlWeb takes the logging features from DataLoggerXP (sold separately) and adds all-new sharing, analyzing, and managing options into a single place. Upload from your pressure gauge and invite colleagues to join you in viewing, editing, and storing your data.

A new way to measure and record

Collect readings with the XP3i pressure gauge

  • All measurement tasks start with improving the world's most popular pressure gauge. If your job requires you to calibrate gauges, carry a single XP3i in your toolbox to replace multiple 'of-scale' rated gauges.
  • If your requirements include a record of a pressure test, add the DataLoggerXP upgrade (sold separately) and turn your pressure gauge into a stand-alone, handheld pressure recorder. The gauge reads and collects the pressure readings, and then stores them until you're ready to download.

CrystalControlWeb cloud software

CrystalControlWeb (CCW) is a new cloud software to manage, customize, save, and download stored data logging runs from the XP3i. CCW is accessed through any web browser, making your pressure gauge's data available to your colleagues worldwide within minutes of collecting it. In addition, CCW includes free features to customize your pressure gauge, like adding and removing units, and features to maximize your reporting options. The cloud service stores all reporting data for easy retrieval, or you can export it to a spreadsheet or pdf file.

CrystalConnect mobile application

The new mobile application lets you communicate with your pressure gauge via Bluetooth. This wireless connection eliminates the need for cables, software drivers, and a PC. Your phone is all you need to view live data and download stored data from the XP3i. Furthermore, connecting to the pressure gauge wirelessly lets you leave the gauge connected in a hazardous area and download the data without removing it.

Easy to use

No menus. No manual? No problem!

  • Four buttons - that's all you need to operate this pressure gauge. Understand every function two minutes after opening the box.
  • With a large display, you can read results from anywhere, even from a distance.
  • The high-contrast liquid crystal display lets you read even in bright sunlight.
  • A bright backlight also lets you read this pressure gauge in the dark.

Stronger. Tougher. Trusted.

Dropped, submerged, over-pressurized and it still reads accurately!

  • Submersible: Sealed against dust and water. IP67 rated for 30 minutes of full submersion under 3' (1 m) of water.
  • Shock resistant: Survives falls with no effect on accuracy. MIL-STD-810H - withstands a five foot drop (without protective boot) and a ten foot drop (with boot) to a steel plate in six orientations.
  • Marine-grade construction: The patented XP3i's nickel-plated housing resists corrosion with the same low-copper, aluminum alloy found on saltwater outboard motors.

Would you know if your gauge was broken?

Some sensors and bourdon gauges read incorrectly after deforming under pressure. You would never know your gauge is broken until you compare it to a reference. This gauge's silicon sensors shatter at very high pressure, but never deform. They always return to their original shape and accuracy, even after accidental overpressure. The gauge's self-diagnostics will indicate a damaged sensor, preventing operation and protecting you from erroneous readings.

Trust every reading

Used everywhere

Consistent performance in the coldest places on earth - Northern Canada

  • In Northern Canada, customers perform hydrostatic testing during winter, when pipelines become accessible by snowcat. They count on the XP3i to be accurate and ready for work when they get there.

XP3i proves itself - Middle East

  • Oil workers on Middle East pipelines operate every day in the blowing sand, under the hot desert sun. They need a reliable, intrinsically safe pressure gauge that works as hard as they do. From pressure testing and equipment calibration to long-term recording, they choose the XP3i.

The same accuracy at any temperature - temperature compensated

  • Active digital temperature compensation corrects the sensor for changes in temperature. This pressure gauge guarantees 0.05% of reading accuracy from -4 to 122°F (-20 to 50°C), an improvement of 18° (10°) from the XP2i.

Free calibration certificate included - with all data!

  • Every XP3i gauge comes with a NIST traceable, ISO 17025 calibration report - from the A2LA (certificate 2601.01) accredited and internationally recognizable by ILAC calibration lab - with test data at five temperatures, proving these gauges meet specifications throughout their full temperature range.

Intrinsically safe recorder

Now record 200 million data points

When you purchase a DataLoggerXP (sold separately) model, you transform your XP3i into a portable pressure data logger. Leave your pressure gauge on location as it records and timestamps readings for months at a time. Start and stop recordings with a single button and store multiple data sets.

DataLoggerXP (sold separately) is ideal for:

  • Pipeline leak testing
  • Wellhead monitoring
  • Chart recorder replacement
  • Diagnostics - capture intermittent or transient events, and many more
  • Extended battery life: Record up to one year with ultra-low power mode

Saves money

From outlasting other equipment to retaining high accuracy, the XP3i is the most valuable pressure equipment you will own

One XP3i replaces multiple test gauges

Your savings start because of the 0.05% of reading accuracy - the highest in class for handheld test gauges. Of scale gauges must be used as close as possible to their full-scale value to maximize accuracy, but the XP3i doesn't have this issue as its of reading accuracy allows it to maintain its accuracy over a wide range. Using this pressure gauge is like carrying multiple conventional gauges.

Save on recalibration costs

All electronic equipment is subjected to long-term shifts in its accuracy, thus requiring recalibration. However, because you only purchased one XP3i instead of four or more conventional gauges, you only have to recalibrate one instead of five. These savings continue each year when it’s recalibration time.

Maintained accuracy

The XP3i is built on the long-term success and reliability of the industry favorite XP2i. We know from our decade-plus years of customer feedback that when the gauge is due for recalibration, it often doesn’t need any adjustments. This leads most companies to perform a pressure check, bypassing a full recalibration if possible. This continued accuracy further reduces and sometimes eliminates recalibration costs.

Last longer

The XP3i is designed to perform effectively, even in the harshest environments. From extensive improvements in drop protection design to moving the everyday wear to a replaceable adapter to multiple environmental improvements, durability is one of the XP3i’s strongest features. This leads to the gauge lasting much longer than conventional equipment, further lowering the overall cost of ownership.

Calibration reminders and alerts

Tracking calibration intervals

Keeping track of the calibration intervals for all test equipment can be a challenging task in which human error can occur. Calibration stickers or certificates can be misplaced or lost, or the technician may not notice that the gauge is beyond its calibration dates. Even if a company has a system to keep track of these dates, it still requires somebody to notify the technician when recalibrations are due. It also requires the technician to remove the gauge from service once they are notified.

In some industries, auditing of test equipment may result in significant fines if it’s found that a gauge was used beyond its calibration due date.

Never miss a calibration again with the XP3i

  • Automatic upcoming calibration reminders
  • Automatic calibration due date alerts
  • Customizable reminder time (in days or weeks)
  • Optional lock out feature to prevent use after due date

Multiple options available

Reminders:

  • Enter due date to fit your company standards
  • Enter notification time prior to due date (for example two weeks)

Cloud management

While the XP3i will alert users of impending calibration needed, long-term planning is easily attainable using the cloud software CrystalControlWeb. By entering all owned gauges into your CrystalControlWeb organization, you will have all calibration information in one central location. Managing and planning all gauge calibrations becomes a much more manageable task, and assuring that gauges are not used past their recalibration dates becomes much easier.

Special functions

Pressure safety valve test

No more guess work. Simply enable this feature to enable a special Pressure Safety Valve (PSV) mode. This gauge captures and displays the relief pressure even if you're not looking at the gauge when the valve opens.

Leak rate

On the Dual Line Display (-DD Model, sold separately), view leak rate or a tared value along with live pressure at the same time. If you have an upgraded version with data logging (sold separately), the second display shows the amount of recorded points.

Custom units

Define custom pressure units with CrystalControlWeb. For example, you can define feet of seawater, tank level, or any torque (N-m or ft-lbs).

Activate the features you need: Simplify your XP3i with CrystalControlWeb software by selecting only the functions you use. Store multiple configurations on your computer, or set all your XP3i gauges to work the same way.

With CrystalControlWeb and your XP3i you can:

  • Enable only the units you use, or add custom units you need (for example, feet of seawater or oz/in2)
  • Disable any button (except for Power and Backlight)
  • Build and load task-specific configurations from your PC
  • Password-protect to prevent changes

Applications

  • Calibration and testing
  • Oil and gas
  • Aerospace
  • Industrial manufacturing
  • Hydraulic systems
  • Chemical and petrochemical
  • Power generation
  • Water and wastewater treatment
  • Pharmaceuticals and biotechnology

Crystal Pressure XP3I-A100PSI Specifications

Accuracy - Absolute Pressure
0 to 40% of Range ±(0.02% of full scale*)
*Full scale is 100% of the range
40 to 110% of Range ±(0.05% of reading)
Range and Resolution
Absolute Pressure Range: 0 to 100 psiA
Display Resolution psi: 0.01
"H2O: 0.1
"Hg: 0.01
mm Hg: 0.1
mm H2O: 1
kg/cm2: 0.0001
bar: 0.0001
mbar: 0.1
kPa: 0.01
MPa: 0.00001
Display
Screen 5.5 digits
Single Line Display 0.68" (17 mm) high
Display Rate 4 readings/second (standard)
Power/Communication
Battery 3 x AA, 1500 hours, typical*
*Typical battery life when operating without backlight or Bluetooth communication.
Ultra Low Power >1 year, typical**
**Enabled when datalogging interval is 20 minutes or longer.
Digital Interface USB-C
Bluetooth Low Energy Version 5.4, up to 100' (30 m) typical
Sensor
Wetted Materials Wrench tight: 316 stainless steel
Finger tight: 316 stainless steel and Viton® (internal o-ring)
Diaphragm Seal Fluid Silicone oil
Connection Crystal CPF female
General Specifications
Environmental Conditions Operating temperature: Fully compensated range from -4 to 122°F (-20 to 50°C)
Storage temperature: -40 to 167°F (-40 to 75°C)
Enclosure Rating IP67
Vibration 10 to 500 Hz, 50 m/s2
Shock 15 g, 11 ms
Surface Fully static dissipative to avoid build-up of electrostatic charge on portable equipment (including the boot)
Dimensions 5.59 x 4.5 x 1.44" (142 x 114.4 x 36.5 mm)
Weight 20.7 oz (580 g)
Click here for complete specifications on the Crystal Pressure XP3I-A100PSI

What's included with the Crystal Pressure XP3I-A100PSI

  • Pressure Gauge
  • Calibration Certificate
  • CPF Connection Fitting
  • Velcro Strap
  • 3 x AA Batteries
  • CrystalConnect Mobile App (free download from the iOS App Store)
  • Free PC Configuration
  • One-Year Warranty

Click on a category to view a selection of compatible accessories with the Ametek Crystal XP3i Series Digital Absolute Pressure Gauge, 0 to 100 psiA, 4.5" dial, ¼" NPT bottom, diecast aluminum housing.

AMETEK Crystal 3009 Hard Carrying Case 3009
For use with accessories, this waterproof case comes complete with egg crate foam.




AMETEK Crystal 2888 Waterproof Hard Carrying Case 2888
Compatible with the System G GaugeCalHP, this hard-shell carrying case is waterproof.




AMETEK Crystal 5203 Magnetic Hanging Strap Kit 5203
Compatible with digital pressure gauges and calibrators, this magnetic hanging strap is an accessory.




Ask a question about Ametek Crystal XP3i Series Digital Absolute Pressure Gauge, 0 to 100 psiA, 4.5" dial, ¼" NPT bottom, diecast aluminum housing

Customer Reviews for the Crystal Pressure XP3I-A100PSI

Crystal Pressure XP3I-A100PSI Offers

Accuracy is 0.05% 'of reading', 0.02% 'of full scale', or 0.05% 'of full scale' - so any XP3i can typically replace several gauges you may have been using. The XP3i is fully temperature compensated – so there is no change in accuracy throughout the entire operating temperature range! The XP3i's case is made from rugged aluminum alloy, fully sealed against dust and water intrusion. Even the USB port is sealed. Circuitry is mounted in shock-absorbing elastomer supports and the batteries are accessible by removing four screws. However, you won’t need to change the batteries often, since 3 AA batteries operate this pressure gauge for up to 1500 hours of continuous use.

Now with USB-C and Bluetooth connections, a free mobile app, and a cloud software service, you can share stored files with any colleague with internet access. In addition, if a recording of a pressure test is required, add the DataLoggerXP upgrade (sold separately) to open a wide range of features and functions.

Features

  • Series ranges up to 10,000 psi, 700 bar, or 70,000 kPa depending on the model purchased
  • Marine grade enclosure resists corrosion (MIL-STD 810)
  • Accuracy not affected from -4 to 122°F (-20 to 50°C)
  • Replaces five or more test gauges
  • Fast pressure safety valve (PSV) mode
  • Easy to use: No menu, no manual, no problem
  • Includes calibration reminders and alerts
  • Bluetooth™ low energy interface to the CrystalConnect mobile app
  • Data logger (sold separately) with extremely large capacity
  • Continuous capture of peak and valley pressure readings
  • Programming interface
  • User-defined units
  • Intrinsically safe: Meets the latest standards as a digital test gauge
  • All welded 316 stainless steel sensor for ranges above 15 psi/1bar

With a Bluetooth connection, you can:

  • Connect in a hazardous environment while retaining intrinsically safe ratings
  • Mount the XP3i in hard-to-reach locations and connect from a safe area
  • Avoid inclement weather by connecting to the XP3i from a climate-controlled office or vehicle
  • Forgot your communication cable? Are drivers not installed? Is the cable damaged? All of these problems go away with a Bluetooth connection!

With the DataLoggerXP upgrade (sold separately)

  • Record over 200 million data points
  • Over an entire year of continuous recording time
  • Start and stop logging runs from your phone or the gauge
  • Download data using a USB connection and a computer or through Bluetooth to the mobile app

With the new CrystalControlWeb cloud software (free for download)

  • Upload stored data from your computer
  • Upload stored data from a file - wirelessly downloaded using your app
  • Share stored data with anybody in your organization
  • Grant user access to your organization through a license key
  • Graph your stored data
  • Customized graph details like line color, axis minimum and maximums, and run and test names
  • Configure the settings on your XP3i
  • Download data to spreadsheets or secure, tamper-proof pdf files

The best is now better!

The new XP3i takes everything you love from the XP2i, like:

  • Easy to use: Just pick up an XP3i and you'll be an expert in minutes. It's as easy as that.
  • Field proven - durable and rugged: Weather tested and drop protected, this pressure gauge is designed to withstand the toughest conditions where you rely on trusted pressure readings.
  • Reliable accuracy whenever: This digital gauge is used in some of the most extreme locations in the world and was designed with temperature compensation to support you wherever you work.

…and adds game-changing features

  • Bluetooth communication: No need to connect to the XP3i by a cable - quickly connect wirelessly using our new CrystalConnect mobile app. Ideal to avoid hazardous locations, inclement weather, and hard-to-reach locations.
  • Twice as accurate as the XP2i: Now with an accuracy of 0.05% of reading, use the XP3i in more places, and replace even more standard gauges. Additionally, this increased accuracy is over a larger temperature-compensated range of -4 to 122°F (-20 to 50°C).
  • Cloud solution: The new cloud software CrystalControlWeb takes the logging features from DataLoggerXP (sold separately) and adds all-new sharing, analyzing, and managing options into a single place. Upload from your pressure gauge and invite colleagues to join you in viewing, editing, and storing your data.

A new way to measure and record

Collect readings with the XP3i pressure gauge

  • All measurement tasks start with improving the world's most popular pressure gauge. If your job requires you to calibrate gauges, carry a single XP3i in your toolbox to replace multiple 'of-scale' rated gauges.
  • If your requirements include a record of a pressure test, add the DataLoggerXP upgrade (sold separately) and turn your pressure gauge into a stand-alone, handheld pressure recorder. The gauge reads and collects the pressure readings, and then stores them until you're ready to download.

CrystalControlWeb cloud software

CrystalControlWeb (CCW) is a new cloud software to manage, customize, save, and download stored data logging runs from the XP3i. CCW is accessed through any web browser, making your pressure gauge's data available to your colleagues worldwide within minutes of collecting it. In addition, CCW includes free features to customize your pressure gauge, like adding and removing units, and features to maximize your reporting options. The cloud service stores all reporting data for easy retrieval, or you can export it to a spreadsheet or pdf file.

CrystalConnect mobile application

The new mobile application lets you communicate with your pressure gauge via Bluetooth. This wireless connection eliminates the need for cables, software drivers, and a PC. Your phone is all you need to view live data and download stored data from the XP3i. Furthermore, connecting to the pressure gauge wirelessly lets you leave the gauge connected in a hazardous area and download the data without removing it.

Easy to use

No menus. No manual? No problem!

  • Four buttons - that's all you need to operate this pressure gauge. Understand every function two minutes after opening the box.
  • With a large display, you can read results from anywhere, even from a distance.
  • The high-contrast liquid crystal display lets you read even in bright sunlight.
  • A bright backlight also lets you read this pressure gauge in the dark.

Stronger. Tougher. Trusted.

Dropped, submerged, over-pressurized and it still reads accurately!

  • Submersible: Sealed against dust and water. IP67 rated for 30 minutes of full submersion under 3' (1 m) of water.
  • Shock resistant: Survives falls with no effect on accuracy. MIL-STD-810H - withstands a five foot drop (without protective boot) and a ten foot drop (with boot) to a steel plate in six orientations.
  • Marine-grade construction: The patented XP3i's nickel-plated housing resists corrosion with the same low-copper, aluminum alloy found on saltwater outboard motors.

Would you know if your gauge was broken?

Some sensors and bourdon gauges read incorrectly after deforming under pressure. You would never know your gauge is broken until you compare it to a reference. This gauge's silicon sensors shatter at very high pressure, but never deform. They always return to their original shape and accuracy, even after accidental overpressure. The gauge's self-diagnostics will indicate a damaged sensor, preventing operation and protecting you from erroneous readings.

Trust every reading

Used everywhere

Consistent performance in the coldest places on earth - Northern Canada

  • In Northern Canada, customers perform hydrostatic testing during winter, when pipelines become accessible by snowcat. They count on the XP3i to be accurate and ready for work when they get there.

XP3i proves itself - Middle East

  • Oil workers on Middle East pipelines operate every day in the blowing sand, under the hot desert sun. They need a reliable, intrinsically safe pressure gauge that works as hard as they do. From pressure testing and equipment calibration to long-term recording, they choose the XP3i.

The same accuracy at any temperature - temperature compensated

  • Active digital temperature compensation corrects the sensor for changes in temperature. This pressure gauge guarantees 0.05% of reading accuracy from -4 to 122°F (-20 to 50°C), an improvement of 18° (10°) from the XP2i.

Free calibration certificate included - with all data!

  • Every XP3i gauge comes with a NIST traceable, ISO 17025 calibration report - from the A2LA (certificate 2601.01) accredited and internationally recognizable by ILAC calibration lab - with test data at five temperatures, proving these gauges meet specifications throughout their full temperature range.

Intrinsically safe recorder

Now record 200 million data points

When you purchase a DataLoggerXP (sold separately) model, you transform your XP3i into a portable pressure data logger. Leave your pressure gauge on location as it records and timestamps readings for months at a time. Start and stop recordings with a single button and store multiple data sets.

DataLoggerXP (sold separately) is ideal for:

  • Pipeline leak testing
  • Wellhead monitoring
  • Chart recorder replacement
  • Diagnostics - capture intermittent or transient events, and many more
  • Extended battery life: Record up to one year with ultra-low power mode

Saves money

From outlasting other equipment to retaining high accuracy, the XP3i is the most valuable pressure equipment you will own

One XP3i replaces multiple test gauges

Your savings start because of the 0.05% of reading accuracy - the highest in class for handheld test gauges. Of scale gauges must be used as close as possible to their full-scale value to maximize accuracy, but the XP3i doesn't have this issue as its of reading accuracy allows it to maintain its accuracy over a wide range. Using this pressure gauge is like carrying multiple conventional gauges.

Save on recalibration costs

All electronic equipment is subjected to long-term shifts in its accuracy, thus requiring recalibration. However, because you only purchased one XP3i instead of four or more conventional gauges, you only have to recalibrate one instead of five. These savings continue each year when it’s recalibration time.

Maintained accuracy

The XP3i is built on the long-term success and reliability of the industry favorite XP2i. We know from our decade-plus years of customer feedback that when the gauge is due for recalibration, it often doesn’t need any adjustments. This leads most companies to perform a pressure check, bypassing a full recalibration if possible. This continued accuracy further reduces and sometimes eliminates recalibration costs.

Last longer

The XP3i is designed to perform effectively, even in the harshest environments. From extensive improvements in drop protection design to moving the everyday wear to a replaceable adapter to multiple environmental improvements, durability is one of the XP3i’s strongest features. This leads to the gauge lasting much longer than conventional equipment, further lowering the overall cost of ownership.

Calibration reminders and alerts

Tracking calibration intervals

Keeping track of the calibration intervals for all test equipment can be a challenging task in which human error can occur. Calibration stickers or certificates can be misplaced or lost, or the technician may not notice that the gauge is beyond its calibration dates. Even if a company has a system to keep track of these dates, it still requires somebody to notify the technician when recalibrations are due. It also requires the technician to remove the gauge from service once they are notified.

In some industries, auditing of test equipment may result in significant fines if it’s found that a gauge was used beyond its calibration due date.

Never miss a calibration again with the XP3i

  • Automatic upcoming calibration reminders
  • Automatic calibration due date alerts
  • Customizable reminder time (in days or weeks)
  • Optional lock out feature to prevent use after due date

Multiple options available

Reminders:

  • Enter due date to fit your company standards
  • Enter notification time prior to due date (for example two weeks)

Cloud management

While the XP3i will alert users of impending calibration needed, long-term planning is easily attainable using the cloud software CrystalControlWeb. By entering all owned gauges into your CrystalControlWeb organization, you will have all calibration information in one central location. Managing and planning all gauge calibrations becomes a much more manageable task, and assuring that gauges are not used past their recalibration dates becomes much easier.

Special functions

Pressure safety valve test

No more guess work. Simply enable this feature to enable a special Pressure Safety Valve (PSV) mode. This gauge captures and displays the relief pressure even if you're not looking at the gauge when the valve opens.

Leak rate

On the Dual Line Display (-DD Model, sold separately), view leak rate or a tared value along with live pressure at the same time. If you have an upgraded version with data logging (sold separately), the second display shows the amount of recorded points.

Custom units

Define custom pressure units with CrystalControlWeb. For example, you can define feet of seawater, tank level, or any torque (N-m or ft-lbs).

Activate the features you need: Simplify your XP3i with CrystalControlWeb software by selecting only the functions you use. Store multiple configurations on your computer, or set all your XP3i gauges to work the same way.

With CrystalControlWeb and your XP3i you can:

  • Enable only the units you use, or add custom units you need (for example, feet of seawater or oz/in2)
  • Disable any button (except for Power and Backlight)
  • Build and load task-specific configurations from your PC
  • Password-protect to prevent changes

Applications

  • Calibration and testing
  • Oil and gas
  • Aerospace
  • Industrial manufacturing
  • Hydraulic systems
  • Chemical and petrochemical
  • Power generation
  • Water and wastewater treatment
  • Pharmaceuticals and biotechnology

Crystal Pressure XP3I-A100PSI Specifications

Accuracy - Absolute Pressure
0 to 40% of Range ±(0.02% of full scale*)
*Full scale is 100% of the range
40 to 110% of Range ±(0.05% of reading)
Range and Resolution
Absolute Pressure Range: 0 to 100 psiA
Display Resolution psi: 0.01
"H2O: 0.1
"Hg: 0.01
mm Hg: 0.1
mm H2O: 1
kg/cm2: 0.0001
bar: 0.0001
mbar: 0.1
kPa: 0.01
MPa: 0.00001
Display
Screen 5.5 digits
Single Line Display 0.68" (17 mm) high
Display Rate 4 readings/second (standard)
Power/Communication
Battery 3 x AA, 1500 hours, typical*
*Typical battery life when operating without backlight or Bluetooth communication.
Ultra Low Power >1 year, typical**
**Enabled when datalogging interval is 20 minutes or longer.
Digital Interface USB-C
Bluetooth Low Energy Version 5.4, up to 100' (30 m) typical
Sensor
Wetted Materials Wrench tight: 316 stainless steel
Finger tight: 316 stainless steel and Viton® (internal o-ring)
Diaphragm Seal Fluid Silicone oil
Connection Crystal CPF female
General Specifications
Environmental Conditions Operating temperature: Fully compensated range from -4 to 122°F (-20 to 50°C)
Storage temperature: -40 to 167°F (-40 to 75°C)
Enclosure Rating IP67
Vibration 10 to 500 Hz, 50 m/s2
Shock 15 g, 11 ms
Surface Fully static dissipative to avoid build-up of electrostatic charge on portable equipment (including the boot)
Dimensions 5.59 x 4.5 x 1.44" (142 x 114.4 x 36.5 mm)
Weight 20.7 oz (580 g)
Click here for complete specifications on the Crystal Pressure XP3I-A100PSI

What's included with the Crystal Pressure XP3I-A100PSI

  • Pressure Gauge
  • Calibration Certificate
  • CPF Connection Fitting
  • Velcro Strap
  • 3 x AA Batteries
  • CrystalConnect Mobile App (free download from the iOS App Store)
  • Free PC Configuration
  • One-Year Warranty

Click on a category to view a selection of compatible accessories with the Ametek Crystal XP3i Series Digital Absolute Pressure Gauge, 0 to 100 psiA, 4.5" dial, ¼" NPT bottom, diecast aluminum housing.

AMETEK Crystal 3009 Hard Carrying Case 3009
For use with accessories, this waterproof case comes complete with egg crate foam.




AMETEK Crystal 2888 Waterproof Hard Carrying Case 2888
Compatible with the System G GaugeCalHP, this hard-shell carrying case is waterproof.




AMETEK Crystal 5203 Magnetic Hanging Strap Kit 5203
Compatible with digital pressure gauges and calibrators, this magnetic hanging strap is an accessory.




Ask a question about Ametek Crystal XP3i Series Digital Absolute Pressure Gauge, 0 to 100 psiA, 4.5" dial, ¼" NPT bottom, diecast aluminum housing

Customer Reviews for the Crystal Pressure XP3I-A100PSI

More Crystal Pressure Products
