Designed for 1in IPS PVC pipes, this flowmeter features 5 to 35GPM (Schedule 40) and 4 to 26GPM (Schedule 80) ratings.
Designed for 1in IPS PVC pipes, this flowmeter features 5 to 35GPM (Schedule 40) and 4 to 26GPM (Schedule 80) ratings.
Features
| Pipe Dimensions | Horizontal Installation: 1" Vertical Installation: 1½", 2" |
| Maximum Working Pressure | 75 PSI (5.17 bar) at 70°F (21°C) |
| Max. Fluid Temperature | 190°F / 88°C at 0 PSI |
| Full Scale Accuracy | ±10% (5x pipe ID minimum inlet pipe length / 2x pipe ID min outlet pipe length) ±5% (10x pipe ID minimum inlet pipe length / 5x pipe ID min outlet pipe length) |
| Material | Meter Body: Acrylic Gasket: Neoprene Float: PVDF |
| Connection Type | Saddle |
| Pipe Capability | PVC Schedule 40 and Schedule 80 (12% higher reading on sch 80 pipe) Copper Tube Type K and L |
| Weight | 1" to 4" Pipe: 1 lbs. (.454kg) 6" and 8" Pipe: 2 lbs. (.907 kg) |
| Pipe Dimensions | Horizontal Installation: 1" Vertical Installation: 1½", 2" |
| Maximum Working Pressure | 75 PSI (5.17 bar) at 70°F (21°C) |
| Max. Fluid Temperature | 190°F / 88°C at 0 PSI |
| Full Scale Accuracy | ±10% (5x pipe ID minimum inlet pipe length / 2x pipe ID min outlet pipe length) ±5% (10x pipe ID minimum inlet pipe length / 5x pipe ID min outlet pipe length) |
| Material | Meter Body: Acrylic Gasket: Neoprene Float: PVDF |
| Connection Type | Saddle |
| Pipe Capability | PVC Schedule 40 and Schedule 80 (12% higher reading on sch 80 pipe) Copper Tube Type K and L |
| Weight | 1" to 4" Pipe: 1 lbs. (.454kg) 6" and 8" Pipe: 2 lbs. (.907 kg) |
