Blue-White F-30300P Flowmeter for 3in IPS PVC Pipes, 45 to 240GPM (SCH 40), 40 to 215GPM (SCH 80)

Model: 13006-000 | Order No: F-30300P

Designed for 3in IPS PVC pipes, this flowmeter features 45 to 240GPM (Schedule 40) and 40 to 215GPM (Schedule 80) ratings.

Designed for 3in IPS PVC pipes, this flowmeter features 45 to 240GPM (Schedule 40) and 40 to 215GPM (Schedule 80) ratings.

Sale Price $173.63 USD
Regular Price $179.00 USD
Availability 4 to 5 Weeks
Quantity

Blue-White 13006-000 Offers

Features

  • Well suited for closed pipe installations
  • Easy to read dual scale (SCH 40 / SCH 80), screen printed on both sides of the meter body
  • Acceptable for outdoor installations (direct sunlight okay)
  • Pitot Tube (impact tube) design makes it easy to install on existing pipe
  • One piece, machined acrylic meter body
  • Included SS clamps and gasket seal
  • For use on PVC or Copper Pipes

Blue-White 13006-000 Specifications

Pipe Dimensions Horizontal Installation: 3"
Vertical Installation: 1.5", 2"
Maximum Working Pressure 75 PSI (5.17 bar) at 70°F (21°C)
Max. Fluid Temperature 190°F / 88°C at 0 PSI
Full Scale Accuracy ±10% (5x pipe ID minimum inlet pipe length / 2x pipe ID min outlet pipe length)
±5% (10x pipe ID minimum inlet pipe length / 5x pipe ID min outlet pipe length)
Material Meter Body: Acrylic
Gasket: Neoprene
Float: PVDF
Connection Type Saddle
Pipe Capability PVC Schedule 40 and Schedule 80 (12% higher reading on sch 80 pipe)
Copper Tube Type K and L
Weight 1" to 4" Pipe: 1 lbs. (.454kg)
6" and 8" Pipe: 2 lbs. (.907 kg)
Click here for complete specifications on the Blue-White 13006-000

What's included with the Blue-White 13006-000

  • Flow Meter
  • Stainless Steel Clamp
  • Gasket Seal
