Blue-White F-42050LK-16 K-Series Flowmeter with Hastelloy Guide Rod, 10 to 50GPM, 1in Female NPT

Model: F-42050LK-16

Equipped with a hastelloy guide rod, this flowmeter has a 10 to 50GPM (40 to 200LPM) flow rate and 1in Female NPT adapter pipe size.

Equipped with a hastelloy guide rod, this flowmeter has a 10 to 50GPM (40 to 200LPM) flow rate and 1in Female NPT adapter pipe size.

Sale Price $699.37 USD
Regular Price $721.00 USD
Availability 2 to 3 Weeks
Quantity

Blue-White F-42050LK-16 Offers

This flowmeter features a white back reflector for easy reading.

Features

  • Tough machined acrylic meter body, highly polished to a clear finish
  • Direct reading permanent scale
  • 1in F/NPT or 1-1/2in M/NPT adapters with high grade Viton o-ring seals
  • 316 stainless steel or Hastelloy rod guided floats
  • Acceptable in direct sunlight applications

Blue-White F-42050LK-16 Specifications

Max. Working Pressure 130psi (8.9 bar) @ 70°F (21°C)
Max. Fluid Temperature (C) @ 0 PSI 130°F (54°C) @ 0psi
Full Scale Accuracy ±5%
Calibration Fluid Water, specific gravity 1.0
Scale Length 4in (10.16cm)
Environment Acceptable for direct sunlight exposure
Maximum Pressure Drop (PSI) 2
Click here for complete specifications on the Blue-White F-42050LK-16

What's included with the Blue-White F-42050LK-16

  • Blue-White F-42050LK-16 K-Series Flowmeter with Hastelloy Guide Rod, 10 to 50GPM, 1in Female NPT
