Strong and durable, this variable area flow meter features a solid, one-piece machined acrylic body that is annealed for chemical resistance and a contrasting background and imprinted scale for effortless meter readings. In addition, this meter features a GPM of 0.2 to 2 and an ⅜" (1.58 cm) adapter f/npt.
Strong and durable, this variable area flow meter features a solid, one-piece machined acrylic body that is annealed for chemical resistance and a contrasting background and imprinted scale for effortless meter readings. In addition, this meter features a GPM of 0.2 to 2 and an ⅜" (1.58 cm) adapter f/npt.
Features
| GPM | 0.2 to 2 |
| LPM | 0.75 to 7.5 |
| Adapter F/NPT | ⅜" (1.58 cm) |
| Materials | Float: 316 SS Meter body: Machined acrylic Adapter: Polypropylene Guide rod: 316 SS O-ring material: FKM |
| Maximum Working Pressure | 250 psig (17.2 bar) at 70°F (21°C) |
| Maximum Fluid Temperature | 200°F (93°C) at 0 PSI |
| Full Scale Accuracy | ±5% |
| Calibration Fluid | Water, specific gravity 1 |
| Scale Length | 4" (100 mm) approximately |
| Environment | Acceptable for direct sunlight exposure |
| Dimensions | 8⅜ x 4½" (21.27 x 11.43 cm) |
| Approximate Shipping Weight | 2 lbs (0.907 kg) |
| GPM | 0.2 to 2 |
| LPM | 0.75 to 7.5 |
| Adapter F/NPT | ⅜" (1.58 cm) |
| Materials | Float: 316 SS Meter body: Machined acrylic Adapter: Polypropylene Guide rod: 316 SS O-ring material: FKM |
| Maximum Working Pressure | 250 psig (17.2 bar) at 70°F (21°C) |
| Maximum Fluid Temperature | 200°F (93°C) at 0 PSI |
| Full Scale Accuracy | ±5% |
| Calibration Fluid | Water, specific gravity 1 |
| Scale Length | 4" (100 mm) approximately |
| Environment | Acceptable for direct sunlight exposure |
| Dimensions | 8⅜ x 4½" (21.27 x 11.43 cm) |
| Approximate Shipping Weight | 2 lbs (0.907 kg) |
