Image is for reference only, refer to product info for complete details.
Works for industrial applications requiring damping, this liquid fillable gauge is ideal for liquids and gases that do not strike the brass measuring system and has a pressure range of 0 to 100 psi.
Works for industrial applications requiring damping, this liquid fillable gauge is ideal for liquids and gases that do not strike the brass measuring system and has a pressure range of 0 to 100 psi.
| Pressure Range | 0 to 100 psi |
| Accuracy | ±1% of span |
| Dial Size | 4" (100 mm) |
| Bezel | 304 stainless steel crimped ring |
| Window | Polycarbonate |
| Dial | Dished aluminum, white background, black figures and graduations |
| Pointer | Aluminum, black finish |
| Bourdon Tube | Phosphor bronze |
| Movement | Brass, with underload/overload stops |
| Connection | Brass in one piece, lower mount, ½" NPT male, G ½" BSP |
| Operating Temperature | 140°F (60°C) |
| Case | 304 stainless steel |
