Image is for reference only, refer to product info for complete details.
Works for industrial applications requiring damping, this liquid fillable gauge is ideal for liquids and gases that do not strike the brass measuring system and has a pressure range of 0 to 1000 psi.
Works for industrial applications requiring damping, this liquid fillable gauge is ideal for liquids and gases that do not strike the brass measuring system and has a pressure range of 0 to 1000 psi.
| Pressure Range | 0 to 1000 psi |
| Accuracy | ±1.6% of span |
| Dial Size | 2.5" (63 mm) |
| Bezel | 304 stainless steel bayonet ring |
| Window | Toughened safety glass |
| Dial | Dished aluminum, white background, black figures and graduations |
| Pointer | Aluminum, black finish |
| Bourdon Tube | Phosphor bronze |
| Movement | Brass |
| Connection | Brass in one piece, lower mount, ¼" NPT male, G ¼" BSP |
| Operating Temperature | 140°F (60°C) |
| Case | 304 stainless steel |
