With a single digital push button, both zero and span are calibrated properly, nothing else is required. Features a range of 0 to 10 in w.c.
With a single digital push button, both zero and span are calibrated properly, nothing else is required. Features a range of 0 to 10 in w.c.
Discontinued!
This product has been discontinued and is no longer available.
This is the direct replacement:
Features
| Service | Air and non-combustible, compatible gases |
| Accuracy | ±2% FS |
| Stability | ±1% FS/year |
| Temperature Range | 32 to 122°F (0 to 50°C) |
| Pressure Range | 2 psi (13.8 kPa) |
| Thermal Effect on Span | ±0.11% FS/°F (±0.19% FS/°C) typ |
| Thermal Effect on Zero | 616KD-X0: 0.6%/°F (1%/°C) 616KD-X1: 0.3%/°F (0.5%/°C) 616KD-X2: 0.2%/°F (0.33%/°C) 616KD-X3: 0.12%/°F (0.2%/°C) 616KD-X4: 0.06%/°F (0.1%/°C) FS max |
| Power Supply | 16 to 35 VDC (2 or 3 wire), 20 to 28 VAC (3 wire) |
| Zero & Span Adjustments | Push button |
| Loop Resistance | DC: 1000 Ω max AC: 1200 Ω max |
| Current Consumption | 21 mA max |
| Electrical Connections | Screw-type terminal block |
| Process Connections | Barbed, dual size to fit 1/8" & 3/16" (3 mm & 5 mm) ID rubber or vinyl tubing |
| Mounting Orientation | Position insensitive |
| Weight | 1.8 oz (51 g) |
| Service | Air and non-combustible, compatible gases |
| Accuracy | ±2% FS |
| Stability | ±1% FS/year |
| Temperature Range | 32 to 122°F (0 to 50°C) |
| Pressure Range | 2 psi (13.8 kPa) |
| Thermal Effect on Span | ±0.11% FS/°F (±0.19% FS/°C) typ |
| Thermal Effect on Zero | 616KD-X0: 0.6%/°F (1%/°C) 616KD-X1: 0.3%/°F (0.5%/°C) 616KD-X2: 0.2%/°F (0.33%/°C) 616KD-X3: 0.12%/°F (0.2%/°C) 616KD-X4: 0.06%/°F (0.1%/°C) FS max |
| Power Supply | 16 to 35 VDC (2 or 3 wire), 20 to 28 VAC (3 wire) |
| Zero & Span Adjustments | Push button |
| Loop Resistance | DC: 1000 Ω max AC: 1200 Ω max |
| Current Consumption | 21 mA max |
| Electrical Connections | Screw-type terminal block |
| Process Connections | Barbed, dual size to fit 1/8" & 3/16" (3 mm & 5 mm) ID rubber or vinyl tubing |
| Mounting Orientation | Position insensitive |
| Weight | 1.8 oz (51 g) |
