Extech EX542 TRMS AC/DC Multimeter/Data Logger, 1000 V/20 A

Model: EX542 | UPC: 793950375426

Extech EX542 TRMS AC/DC Multimeter/Data Logger, 1000 V/20 A-

More Extech Products

Ask an Expert

Extech EX542 TRMS AC/DC Multimeter/Data Logger, 1000 V/20 A

Model: EX542 | UPC: 793950375426

12-function True RMS AC/DC industrial multimeter logs up to 9,999 readings internally and transmits data wirelessly directly to your PC up to 30' (10m) away.

12-function True RMS AC/DC industrial multimeter logs up to 9,999 readings internally and transmits data wirelessly directly to your PC up to 30' (10m) away.

Discontinued!

This product has been discontinued and is no longer available. There is no direct replacement. Don't worry, we have some options to help you find what you need:

Visit our Voltage category for similar products.

Or let's do a search and help you find what you need:

Extech EX542 Offers

Features

  • Datalog up to 9,999 readings with wireless USB interface capability to transmit readings to your PC in real time
  • 433MHz transmission frequency is suitable for use in most regions outside North America
  • Measures AC/DC voltage and current, resistance, diode test, and continuity
  • Capacitance and dual sensitivity frequency functions for electrical and electronic applications
  • True RMS for accurate AC measurements when measuring distorted or noisy waveforms
  • Built-in Type K thermometer for surface or air temperature measurements
  • 0.06% basic accuracy
  • Backlit triple LCD display includes two sub-displays for simultaneous indication of frequency with voltage and memory data/location information
  • 1000V input protection on all functions
  • Diode open circuit voltage of 2.8V DC
  • Auto power off with disable feature
  • CAT IV 600V safety rating

Extech EX542 Specifications

AC/DC Voltage Range 0.01mV to 1000V
AC/DC Current Range 0.01µA to 20A
Resistance Range 0.01Ω to 40MΩ
Capacitance Range 0.001nF to 40mF
Frequency Range Electronic: 0.001Hz to 100MHz; Electrical: 40Hz to 4kHz
Duty Cycle Range 0.1 to 99.90%
Type K Temperature Range -50 to 1382°F (-45 to 750°C)
Dimensions 7.25 x 3.25 x 2.25" (184 x 83 x 57mm)
Weight 12.3 oz (349g)

What's included with the Extech EX542

  • AC/DC Multimeter/Datalogger
  • Double Moulded Test Leads
  • Type K Bead Wire Temperature Probe
  • Remote Receiver with USB Cable
  • Windows Compatible Software
  • Magnetic Hanging Strap
  • Hard Carrying Case
  • 1 x 9V Battery

Ask a question about Extech EX542 TRMS AC/DC Multimeter/Data Logger, 1000 V/20 A

Customer Reviews for the Extech EX542

Extech EX542 Offers

Features

  • Datalog up to 9,999 readings with wireless USB interface capability to transmit readings to your PC in real time
  • 433MHz transmission frequency is suitable for use in most regions outside North America
  • Measures AC/DC voltage and current, resistance, diode test, and continuity
  • Capacitance and dual sensitivity frequency functions for electrical and electronic applications
  • True RMS for accurate AC measurements when measuring distorted or noisy waveforms
  • Built-in Type K thermometer for surface or air temperature measurements
  • 0.06% basic accuracy
  • Backlit triple LCD display includes two sub-displays for simultaneous indication of frequency with voltage and memory data/location information
  • 1000V input protection on all functions
  • Diode open circuit voltage of 2.8V DC
  • Auto power off with disable feature
  • CAT IV 600V safety rating
Show More...

Extech EX542 Specifications

AC/DC Voltage Range 0.01mV to 1000V
AC/DC Current Range 0.01µA to 20A
Resistance Range 0.01Ω to 40MΩ
Capacitance Range 0.001nF to 40mF
Frequency Range Electronic: 0.001Hz to 100MHz; Electrical: 40Hz to 4kHz
Duty Cycle Range 0.1 to 99.90%
Type K Temperature Range -50 to 1382°F (-45 to 750°C)
Dimensions 7.25 x 3.25 x 2.25" (184 x 83 x 57mm)
Weight 12.3 oz (349g)

What's included with the Extech EX542

  • AC/DC Multimeter/Datalogger
  • Double Moulded Test Leads
  • Type K Bead Wire Temperature Probe
  • Remote Receiver with USB Cable
  • Windows Compatible Software
  • Magnetic Hanging Strap
  • Hard Carrying Case
  • 1 x 9V Battery

Ask a question about Extech EX542 TRMS AC/DC Multimeter/Data Logger, 1000 V/20 A

Customer Reviews for the Extech EX542
