Fluke 717-500G Pressure Calibrator, 0 to 500 PSI

Model: 717-500G | UPC: 095969327688

Downloads:

Fluke 717-500G Pressure Calibrator, 0 to 500 PSI

Model: 717-500G | UPC: 095969327688

Pressure switch test function captures set, reset and Deadband values of a pressure switch. Measure mA with 0.015% accuracy and 0.001 mA resolution, while sourcing 24V loop power.

Your Price	$2324.99 USD
Availability	6 to 7 Weeks6 to 7 Weeks
Quantity	Quantity

Traceable Calibration Certificate for your 717-500G Pressure Calibrator

Yes, I would like to add a Traceable Calibration Certificate (Model CERTIMPG4) for only $415.00 USD

Traceable Calibration Certificate for your 717-500G Pressure Calibrator

Yes, I would like to add a Traceable Calibration Certificate (Model CERTIMPG4) for only $415.00 USD

Recommended Accessories

Fluke TL220 Suregrip Industrial Test Lead Set

TL220

Fluke i1010 AC/DC Current Clamp

I1010

Fluke C550 Premium Tool Bag

C550

Fluke TP74 Lantern Tip Test Probe Set, 1000 V, 10 A

TP74

Fluke AC280 SureGrip Hook Clips

AC280

Fluke 717-500G Offers

Features

1/8 NPT female pressure fitting
Compatible with non-corrosive Gases and liquids
Zero, min, max, and hold functions
Calibrate P/I instruments with simultaneous pressure and current measurement
Error% calculation of mA measurements for quick pass-fail decisions
Long lasting battery life
Holster features test lead storage
Compatible with Toolpack magnetic hanging system
New switch test

Applications

Oil and Gas
Pharmaceutical
Water and wastewater
Food and Beverage
Power Generation

Application Selection Guide


Model number	754	721/721Ex	719Pro	719	718	717	700G	3130	2700G	Dead-weight Testers
Application
Calibrating pressure transmitters (field)	●	●	Ideal	●	●	●		●
Calibrating pressure transmitters (bench)	●	●	●	●	●	●		Ideal		●
Calibrating HART Smart transmitters	Ideal
Documenting pressure transmitter calibrations	Ideal
Testing pressure switches in the field	Ideal	●	●	●	●	●		●
Testing pressure switches on the bench	●	●	●	●	●	●		Ideal
Documenting pressure switch tests	Ideal
Testing pressure switches with live (voltage) contacts	Ideal
Gas custody transfer computer tests	●	Ideal	●
Verifying process pressure gauges (field)	Ideal	●	●	●	●	●	●
Verifying process pressure gauges (bench)	●	●	●	●	●	●		●	●	Ideal
Logging pressure measurements	●						Ideal		●
Testing pressure devices using a reference gauge									Ideal
Hydrostatic vessel testing							Ideal
Leak testing (pressure measurement logging)	●						Ideal

Pressure Calibration Selection Guide

Fluke 717-500G Specifications

Range	0-500 psi
Max	1000 psi
Accuracy 6 month	0.025 %
Accuracy 1 year	0.035 %
Loop Supply	24 V dc nominal
Maximum voltage applied between either an mA terminal and earth ground or between the mA terminals	30 V
Strorage Temp.	-40℃ to 60℃
Operating altitude	3000 meters max.
Vibration	Random 2 g, 5 Hz to 500 Hz, per MIL -PRF_28800F, Class 2
Shock	1 meter drop

Click here for complete specifications on the Fluke 717-500G

What's included with the Fluke 717-500G

Protective Yellow Holster with Test Lead Storage
Test Leads and Alligator Clips
Instructions Sheet (14 languages)
NIST-Traceable Calibration Report and Data
Single 9V Alkaline Battery
