Measure AC/DC current up to 100A with this sensor. The sensor boasts an auto-zero function.
Measure AC/DC current up to 100A with this sensor. The sensor boasts an auto-zero function.
Use this Hioki CT7731 AC/DC Auto-Zero Current Sensor to capture precise measurements in changing environments. The auto-zero sensor is built to measure up to 100A, and can be paired with a compatible Hioki display unit to perform testing while on the job.
Features
| Rated Measurement Current | 100A AC/DC |
| Maximum Measurement Current | 100A (requires derating at frequency) |
| Maximum Allowable Peak Input | 150A |
| Bandwidth | DC to 5kHz (-3dB) |
| Accuracy | ±1.8° (typical) |
| Output Rate | 1mV/A |
| Maximum Rated Voltage to Earth | 600V AC/DC (Cat IV) |
| Core Diameter | φ1.3in (33mm) |
| Connection | Hioki PL 14 output |
| Operating Temperature | -13 to 149°F (-25 to 65°C) |
| CE Compliant | Yes |
| Product Length | 0.71in (18mm) main unit, 8.2ft (2.5m) cable |
| Product Width | 2.28in (58mm) |
| Product Height | 5.2in (132mm) |
| Product Weight | 8.8oz (250g) |
| Rated Measurement Current | 100A AC/DC |
| Maximum Measurement Current | 100A (requires derating at frequency) |
| Maximum Allowable Peak Input | 150A |
| Bandwidth | DC to 5kHz (-3dB) |
| Accuracy | ±1.8° (typical) |
| Output Rate | 1mV/A |
| Maximum Rated Voltage to Earth | 600V AC/DC (Cat IV) |
| Core Diameter | φ1.3in (33mm) |
| Connection | Hioki PL 14 output |
| Operating Temperature | -13 to 149°F (-25 to 65°C) |
| CE Compliant | Yes |
| Product Length | 0.71in (18mm) main unit, 8.2ft (2.5m) cable |
| Product Width | 2.28in (58mm) |
| Product Height | 5.2in (132mm) |
| Product Weight | 8.8oz (250g) |
