Image is for reference only, refer to product info for complete details.
Economical general service gauge with a 2" dial size, steel case and copper alloy internals. Features a lower mount style casing, 1/8" NPT connection and a pressure range of 0 to 15 psi.
Economical general service gauge with a 2" dial size, steel case and copper alloy internals. Features a lower mount style casing, 1/8" NPT connection and a pressure range of 0 to 15 psi.
Discontinued!
This product has been discontinued and is no longer available.
This is the direct replacement:
Suited for use with water, oil, air, gas, or other non-corrosive media.
Applications
| Accuracy | ASME Grade B- ±3/2/3% (±2% of range across middle half of scale) |
| Case Size | 2" |
| Case Material | Steel, black painted |
| Case Style | Lower Mount |
| Tube & Socket | Copper alloy |
| Movement | Brass |
| Connection | 1/8" NPT |
| Range | 0 to 15 psi |
| Dial Standard | Dual scale psi and kPa |
| Pointer | Aluminum, black painted |
| Window | Acrylic, twist-in Clearlok |
| Weight | 0.3 lb |
| Accuracy | ASME Grade B- ±3/2/3% (±2% of range across middle half of scale) |
| Case Size | 2" |
| Case Material | Steel, black painted |
| Case Style | Lower Mount |
| Tube & Socket | Copper alloy |
| Movement | Brass |
| Connection | 1/8" NPT |
| Range | 0 to 15 psi |
| Dial Standard | Dual scale psi and kPa |
| Pointer | Aluminum, black painted |
| Window | Acrylic, twist-in Clearlok |
| Weight | 0.3 lb |
