Image is for reference only, refer to product info for complete details.
Economical general service gauge with a 2.5" dial size, steel case and copper alloy internals. Features a lower mount style casing, 1/4" NPT connection and a pressure range of 0 to 200 psi.
Economical general service gauge with a 2.5" dial size, steel case and copper alloy internals. Features a lower mount style casing, 1/4" NPT connection and a pressure range of 0 to 200 psi.
Suited for use with water, oil, air, gas, or other non-corrosive media.
Applications
| Accuracy | ASME Grade B- ±3/2/3%(±2% of range across middle half of scale) |
| Case Size | 2.5" (6.35 cm) |
| Case Material | Steel, black painted |
| Case Style | Lower Mount |
| Tube and Socket | Copper alloy |
| Movement | Brass |
| Connection | 1/4" (0.64 cm) NPT |
| Range | 0 to 200 psi |
| Dial Standard | Dual scale psi and kPa |
| Pointer | Aluminum, black painted |
| Window | Acrylic, twist-in Clearlok |
| Weight | 0.4 lbs (0.2 kg) |
