Accurate and reliable temperature sensor with no electricity and wiring needed, this adjustable angle bimetal thermometer is ideal for eye-level temperature readings with a dial size of 3" (76.2 mm). Come with a turn of the calibration screw and a temperature range of 0 to 200°F.
Accurate and reliable temperature sensor with no electricity and wiring needed, this adjustable angle bimetal thermometer is ideal for eye-level temperature readings with a dial size of 3" (76.2 mm). Come with a turn of the calibration screw and a temperature range of 0 to 200°F.
Features
Applications
| Temperature Range | 0 to 200°F |
| Accuracy | ±1% full scale (ASME B40.3 grade A) |
| Connection | ½" NPT |
| Temperature Sensing Area | Last 2 to 4" of the stem |
| Immersion | Minimum 2" in liquid, and 4" in gas for most ranges. Certain ranges require up to 4" in liquids and 5" in gas. |
| Lens | Glass (standard), acrylic, polycarbonate, laminated safety glass or tempered glass |
| Environmental Protection | P67, NEMA 6 rated (hermetically sealed per ASME B40.3) |
| Dial | Size: 3" (76.2 mm) dial with reset Material: Black marks on satin matte aluminum finish |
| Stem | Length: 4" (101.6 mm) Diameter: ¼" (standard) |
| Temperature Range | 0 to 200°F |
| Accuracy | ±1% full scale (ASME B40.3 grade A) |
| Connection | ½" NPT |
| Temperature Sensing Area | Last 2 to 4" of the stem |
| Immersion | Minimum 2" in liquid, and 4" in gas for most ranges. Certain ranges require up to 4" in liquids and 5" in gas. |
| Lens | Glass (standard), acrylic, polycarbonate, laminated safety glass or tempered glass |
| Environmental Protection | P67, NEMA 6 rated (hermetically sealed per ASME B40.3) |
| Dial | Size: 3" (76.2 mm) dial with reset Material: Black marks on satin matte aluminum finish |
| Stem | Length: 4" (101.6 mm) Diameter: ¼" (standard) |
