Image is for reference only, refer to product info for complete details.
Provides a great variety of economic gauges, this general-purpose gauge is ideal for non-vibrating applications with a black steel case and snap-in plastic lens. In addition, it features a dial size of 2.5" (63.5 mm) and a pressure range of 0 to 100 psi.
Provides a great variety of economic gauges, this general-purpose gauge is ideal for non-vibrating applications with a black steel case and snap-in plastic lens. In addition, it features a dial size of 2.5" (63.5 mm) and a pressure range of 0 to 100 psi.
Features
| Pressure Gauge | 0 to 100 psi |
| Accuracy | 3 – 2 – 3%, ASME grade B |
| Connection | ¼" NPT |
| Temperature Range Limit | Ambient: -40 to 140°F (-40 to 60°C) Process: -40 to 140°F (-40 to 60°C) |
| Case Type | Black steel case, snap-in plastic lens |
| Tube and Socket | Copper alloy |
| Mount Type | Center back |
| Dial Size | 2.5" (63.5 mm) |
| Weight | 0.25 lbs |
