With a carbon monoxide-specific measuring range of 0 to 300 ppm, this M2A series stand-alone sensor offers a transmitter with J-box.
With a carbon monoxide-specific measuring range of 0 to 300 ppm, this M2A series stand-alone sensor offers a transmitter with J-box.
With four operating modes, the stand alone sensor operates with or without a controller.
Features
Applications
| Sensors | Electrochemical |
| Measuring Range | 0 to 300 ppm |
| Resolution | 1 ppm |
| Relays | 5 Amp form 'C' contacts for alarm 1, alarm 2, and fail |
| Display | Alphanumeric OLED display 8 characters per line; 2 lines for gas concentration readout User-friendly calibration and setup |
| Alarm Indication | Visual LEDs. Alarm 1=Amber; Alarm 2=Red; Fail=Red |
| Relative Humidity | 5 to 95% RH non-condensing |
| Operating Voltage | 10 to 30 VDC |
| Housing J-Box | NEMA 4X, explosion proof, watertight, cast aluminum with o-ring seal and epoxy powder coating |
| Sensors | Electrochemical |
| Measuring Range | 0 to 300 ppm |
| Resolution | 1 ppm |
| Relays | 5 Amp form 'C' contacts for alarm 1, alarm 2, and fail |
| Display | Alphanumeric OLED display 8 characters per line; 2 lines for gas concentration readout User-friendly calibration and setup |
| Alarm Indication | Visual LEDs. Alarm 1=Amber; Alarm 2=Red; Fail=Red |
| Relative Humidity | 5 to 95% RH non-condensing |
| Operating Voltage | 10 to 30 VDC |
| Housing J-Box | NEMA 4X, explosion proof, watertight, cast aluminum with o-ring seal and epoxy powder coating |
