This is a handheld triple-wavelength optical laser source with VisiTester technology for singlemode fiber testing at 1310, 1550, and 1625 nm. With an APC connector, ISO/IEC 17025 calibration, and rugged design, it provides stable, repeatable results for telecom, broadband, and FTTH certification and troubleshooting.
This is a handheld triple-wavelength optical laser source with VisiTester technology for singlemode fiber testing at 1310, 1550, and 1625 nm. With an APC connector, ISO/IEC 17025 calibration, and rugged design, it provides stable, repeatable results for telecom, broadband, and FTTH certification and troubleshooting.
Features
| Output Wavelength | 1310, 1550, 1625 nm (laser) 650 nm VisiTester |
| Output Power | -7 dBm ±1 dB (laser) +2 dBm (VisiTester) |
| Adjustable Output Power | Over 7 dB in 0.01 dB steps |
| Short-Term Stability | 0.05 dB (for 15 minutes, after warm-up, ±2°C) |
| Stability Over Temperature | 0.2 dB maximum (typical) |
| Reconnection Repeatability | <0.1 dB at 95% confidence |
| Modulation | 270 Hz 1 kHz 2 kHz ±2% 12 Multi-Fiber ID tones VisiTester blink |
| Spectrum Width | <1 nm (typical, laser) |
| Wavelength Drift | 0.1 to 0.4 nm per °C (typical) |
| Calibration | ISO/IEC 17025 traceable 3-year validity |
| Display | 2.9 x 2.2" (74 x 55 mm) high contrast LCD |
| Power Supply | 2 × AA Alkaline NiMH (USB rechargeable), external USB power |
| Battery Life | 80 to 90 hours typical in Autotest mode |
| Case | Polycarbonate body with rubber edges Moisture resistant 1 m drop tested |
| Temperature | Operating: 5 to 131°F (-15 to 55°C) Storage: -13 to 158°F (-25 to 70°C) Humidity: 0 to 95% RH |
| Warranty | 3 years |
| Dimensions | 7.5 x 4.1 x 1.4" (190 x 105 x 35 mm) |
| Weight | 0.93 lbs (420 g) |
| Output Wavelength | 1310, 1550, 1625 nm (laser) 650 nm VisiTester |
| Output Power | -7 dBm ±1 dB (laser) +2 dBm (VisiTester) |
| Adjustable Output Power | Over 7 dB in 0.01 dB steps |
| Short-Term Stability | 0.05 dB (for 15 minutes, after warm-up, ±2°C) |
| Stability Over Temperature | 0.2 dB maximum (typical) |
| Reconnection Repeatability | <0.1 dB at 95% confidence |
| Modulation | 270 Hz 1 kHz 2 kHz ±2% 12 Multi-Fiber ID tones VisiTester blink |
| Spectrum Width | <1 nm (typical, laser) |
| Wavelength Drift | 0.1 to 0.4 nm per °C (typical) |
| Calibration | ISO/IEC 17025 traceable 3-year validity |
| Display | 2.9 x 2.2" (74 x 55 mm) high contrast LCD |
| Power Supply | 2 × AA Alkaline NiMH (USB rechargeable), external USB power |
| Battery Life | 80 to 90 hours typical in Autotest mode |
| Case | Polycarbonate body with rubber edges Moisture resistant 1 m drop tested |
| Temperature | Operating: 5 to 131°F (-15 to 55°C) Storage: -13 to 158°F (-25 to 70°C) Humidity: 0 to 95% RH |
| Warranty | 3 years |
| Dimensions | 7.5 x 4.1 x 1.4" (190 x 105 x 35 mm) |
| Weight | 0.93 lbs (420 g) |
