Extech EX720 True RMS Clamp Meter, 800A

Model: EX720 | UPC: 793950397206

Extech EX720 True RMS Clamp Meter, 800A-

Downloads:

More Extech Products

Ask an Expert

Extech EX720 True RMS Clamp Meter, 800A

Model: EX720 | UPC: 793950397206

AC Current, True RMS, and Temperature. Full Featured Professional Clamp Meter with an ergonomically designed double molded housing for one-handed operation and comfort.

AC Current, True RMS, and Temperature. Full Featured Professional Clamp Meter with an ergonomically designed double molded housing for one-handed operation and comfort.

Discontinued!

This product has been discontinued and is no longer available.
This is the direct replacement:

Extech EX8xxA Series True RMS AC/DC Clamp Meter with IR thermometer, 0.1 to 1000 A-

Extech EX8xxA Series True RMS AC/DC Clamp Meter with IR thermometer, 0.1 to 1000 A

Model: EX840A

Ergonomically designed with a double-molded housing, this True RMS AC/DC clamp meter, with a CAT IV-600 V rating, provides a better grip for one-hand operation. Additionally, this meter includes a built-in infrared thermometer and laser pointer for non-contact temperature surface measurements.

Learn More

Recommended Accessories

Extech 480172 AC Line Splitter-

Extech 480172 AC Line Splitter

480172

Extech EX720 Offers

Features

  • Functions include AC current, AC/DC voltage, resistance, frequency, capacitance, diode test, continuity
  • Built-in Type K thermometer for contact surface temperature measurements
  • True RMS for accurate AC measurements when measuring distorted or noisy waveforms
  • Large LCD display with LED backlighting
  • Data Hold freezes the reading on the display
  • Peak function captures inrush currents and voltage transients
  • 1.2" (30mm) jaw size accommodates conductors up to 500MCM
  • Auto power off conserves battery life
  • CAT III 600V safety rating

Extech EX720 Specifications

AC Current Range 0.1 to 800A
AC/DC Voltage Range 0.1mV to 600V
Resistance Range 0.1 to 40MΩ
Capacitance Range 0.001nF to 40,000µF
Frequency Range 0.001 to 4kHz
Type K Temperature Range -4 to 1400°F (-20 to 760°C)
Dimensions 9 x 3.1 x 1.9" (229 x 80 x 49mm)
Weight 10.7 oz (303g)
Click here for complete specifications on the Extech EX720

What's included with the Extech EX720

  • AC Clamp Meter
  • Test Leads
  • Type K Bead Wire Temperature Probe
  • Belt Holster
  • 1 x 9V Battery

Click on a category to view a selection of compatible accessories with the Extech EX720 True RMS Clamp Meter, 800A.

Extech 480172 AC Line Splitter 480172
Allows clamp meter to measure AC Current on a 2-wire or 3-wire power cord.
